Product Information
FX80 Base Controller & SD Card with License For 100 Field Devices / 5000 Points and Initial Purchase 1 Year Software Maintenance For FX80 100 - 199 Field Dev.
The FX80 Supervisory Controller is a web-based supervisory-class controller in the Facility Explorer® product family. The FX80 controller manages networks of field controllers using open communication protocols, such as BACnet®, LonWorks®, and the N2 Bus. The FX80 controller supports a full set of building automation features, such as scheduling, alarming, historical data collection and management, data sharing, energy management, totalization, customized control routines, tagging, templates, search, and hierarchies, which are specifically designed for commercial facilities.
Each FX80 controller includes a graphical system user interface with an HTML5 web profile, a configuration tool that you can access with the web browser, and robust security. Remote access is easily achieved using a wired or wireless connection from the Internet or intranet. Multiple users can connect to the FX80 controller concurrently. You can manage security and presentation preferences through user profiles, login IDs, and passwords.
The FX80 Supervisory Controller is a compact DIN rail mountable controller with the capability for remote external input and output points.
Features and Benefits:
• Fully commissioned and licensed out of the box
• Web-based user interface
• Adoption of industry standard communication protocols
• Embedded Configuration Tool
• Modular design
• Small, compact design
• FX Workbench
• Niagara® analytics
Specifications
| Parameter | Specification |
|---|---|
| Enclosure | Plastic |
| Mounting | DIN rail |
| Dimensions (h x w d) | 179 mm x 110 mm x 61 mm (7.05 in. x 4.33 in. x 2.40 in.) |
| Power supply | 24 VAC rated at 24 VA minimum, or 24 VDC rated at 1 A (24 W) minimum |
| Processor | TI AM3352: 1000MHz ARM® Cortex™ A8 |
| RAM memory | 1 GB DDR3 SD RAM |
| Flash memory | Removable micro-SD card with 4 GB flash total storage, 2 GB user storage |
| Environment | Operating temperature: -20°C to 60°C (-4ºF to 140ºF) Storage temperature: -40°C to 85°C (-40ºF to 185ºF) Humidity: 5% to 95%, non-condensing |
| Onboard | Two Ethernet ports: 10/100 MBps Two isolated RS-485 ports with selectable bias and termination 1 USB, 1 Micro USB, Fast USB Bus; Wi-Fi |
| Plug-in options | Two isolated RS-485 ports LON FT/TP-10; RS-232 |
| Network Drivers | |
| Embedded | N2, BACnet, Niagara |
| Direct I/O | |
| Onboard | None |
| Optional | Up to 256 I/O when you use 16 remote I/O modules |
| Local (NDIO) | None |
| Remote I/O | Up to 256 I/O when you use 16 remote I/O modules |
| Compliance | United States UL Listed, File E207782, CCN PAZX, under UL 916, Energy Management Equipment FCC compliant to CFR 47, part 15, subpart C, Class B |
Workbench Requirements
| Parameter | Specification |
|---|---|
| Processor | Intel® Pentium® 4, 1 GHz or higher 102 mm x 92 mm x 67 mm (4 x 3.625 x 2.625 in. ) |
| Operating system | 32-bit: Windows® 10 Pro or Enterprise, Windows 8 Pro or Enterprise, Windows 7 Professional, Enterprise, or Ultimate, or Windows XP® Professional 64-bit: Windows® 10 Pro or Enterprise, Windows 8.1 Pro or Enterprise, Windows 8 Pro or Enterprise, Windows 7 Professional, Enterprise, or Ultimate, Windows Server 2012 Standard or Enterprise with SP2, or Windows Server® 2012 R2 Standard or Enterprise with SP2 |
| Memory | 1 GB minimum, 4 GB or more recommended for larger systems |
| Hard disk | 4 GB minimum, more recommended depending on archiving requirements |
| Network support | Ethernet 10/100 Mbps with RJ-45 connector |
