HE-69120NP-0 Duct Probe RH Transmitter, 2% RH, 0-5/0-10 VDC, with 1k Nickel Temperature Element
Outputs 0-5 or 0-10 VDC for 0-100% RH and adds a passive 1k nickel element for duct temperature.
Needs 12-30 VDC or 18-30 VAC power.
Key Features
- Probe: 6.25 in.
- Wiring: screw terminals
Product Specifications
| Manufacturer | Johnson Controls |
|---|---|
| Model | HE69120NP0 (HE-69120NP-0) |
| RH sensor | Capacitive, 0 to 100% RH |
| RH output | 0-5 VDC or 0-10 VDC, 1k ohm maximum load |
| RH accuracy at 77 deg F | +/-2% RH from 20% to 80% RH; +/-4% RH from 10% to 20% and 80% to 90% RH |
| RH temperature coefficient | -0.03% RH per deg C |
| Temperature element | Thin-film nickel, 1k ohm at 70 deg F, about 3 ohm per deg F; +/-0.34 deg F at 70 deg F |
| Calibration | Includes a certificate of calibration conformance; tested with NIST-compliant equipment |
| Power | 12 to 30 VDC or 18 to 30 VAC, 50/60 Hz, Class 2 |
| Current draw | 5 mA DC, 14 mA AC, excluding load |
| Wiring | Screw terminals: 3-position and 2-position blocks; 16 to 24 AWG (18 AWG preferred) |
| Ambient operating | 32 to 140 deg F, 0 to 100% RH, 85 deg F maximum dew point |
| Survival | -40 to 140 deg F |
| Housing | Blue plastic cover, housing, and probe |
| Dimensions | Duct probe 3.28 x 3.25 x 8.27 in.; probe 6.25 x 0.98 in. |
| Compliance | UL Listed (CCN XAPX, File E27734); plenum rated UL 2043; cUL; CE; RCM |
