RAC18-IP
Details
Details
RAC18-IP Room Application Controller, 18 I/O, Niagara-Enabled IP
Includes a dedicated fan coil application covering 256 variations and is freely programmable in iC Tool or Niagara Workbench (nE2 Link).
Powers wall panels from its RS485 port up to 5 W, about 5 Touch Point panels.
Key Features
- 4 universal inputs, 4 digital inputs, 5 digital outputs, 3 analog outputs, 2 triac outputs
- 1 RS485, 2 Ethernet, 1 USB
Product Specifications
| Manufacturer | iSMA CONTROLLI |
|---|---|
| Model | RAC18-IP |
| Product type | Building automation controller (room application controller) |
| Programming | Freely programmable Room Application Controller; nano EDGE ENGINE; nE2 Link for Niagara; iC Tool |
| Onboard I/O | 4 universal inputs, 4 digital inputs, 5 digital outputs, 3 analog outputs, 2 triac outputs |
| Interfaces | 1 RS485, 2 Ethernet, 1 USB |
| Ethernet | 2-port switch, fail-safe protected for daisy chain |
| RS485 | BACnet MS/TP or Modbus RTU; powers external devices up to 5 W |
| Protocols | BACnet and Modbus over IP and RS485 |
| Application | Dedicated fan coil unit (FCU) application covering 256 variations |
| Power supply | 24 VAC/DC |
