MN7220A2007 Non-Spring Return Direct Coupled Actuator, 175 lb-in, Modulating 0/2-10 VDC or 0/4-20mA, 24 VAC/DC
Accepts a 0-10V, 2-10V, 0-20mA, or 4-20mA control signal.
Needs 24 VAC/DC power.
Holds its position on power loss.
Mounts directly on a 3/8 to 1-1/16 in. round or 3/8 to 11/16 in. square damper shaft.
Key Features
- 0(2)-10 VDC feedback
- Declutch for manual adjustment
Product Specifications
| Manufacturer | Honeywell |
|---|---|
| Model | MN7220A2007 |
| Product type | Non-spring return direct coupled damper actuator (N20 Series) |
| Torque | 175 lb-in (20 Nm) |
| Fail action | Non-spring return (holds position on power loss) |
| Control signal | 0(2)-10 VDC or 0(4)-20mA, set by dip switch; input impedance 100 kOhm (VDC), 500 ohm (mA); autoadapt dip switch |
| Supply power | 24 VAC +/-20%, 50/60 Hz; 24 VDC -10%/+20% |
| Power consumption | 6 VA / 6 W |
| Timing | 95 sec (60 Hz) / 110 sec (50 Hz) |
| Stroke | 95 deg +/-3 deg; mechanical end limits, 0-90 deg in 3 deg steps |
| Aux switches | None; SW2-US aux switch kit available |
| Feedback | 0(2)-10 VDC, +/-1 mA |
| Shaft size | Round 3/8 to 1-1/16 in. (10 to 27 mm); square 3/8 to 11/16 in. (10 to 18 mm) in 45 deg steps |
| Mounting | Self-centering shaft adapter, any orientation; minimum shaft length 7/8 in. (22 mm); declutch for manual adjustment; mechanical position indicator |
| Enclosure | NEMA 2 (USA models); not when mounted upside down |
| Operating temperature | -5 to 140 deg F (-20 to 60 deg C) |
| Storage temperature | -40 to 175 deg F (-40 to 80 deg C) |
| Humidity | 5 to 95% RH, non-condensing |
| Noise | 40 dB(A) max at 1 m |
| Approvals | UL/cUL; UL873 plenum rating, File No. E4436, Guide No. XAPX; CE; C-Tick |
| Design life | 60,000 full strokes; 1.5 million repositions |
| Weight | 3 lb (1.35 kg) |
| Included | 205649 anti-rotation bracket; 172092062 self-centering shaft adapter |
| Accessories | SW2-US aux switch package; 50001194-001 foot mount kit; 32003036-001 weather enclosure; 205860 minimum position potentiometer |
| Honeywell form | 63-2587-03 Rev. 03-19; 63-1303 Rev. 8-04 |
