EasyIO-FW-08V
Details
Details
Product DetailsSpecificationsDownloads
Product Information
Same as FW-8. Includes a built-in Pressure Pick-up Sensor for Air Flow Measurement used in VAV applications.
The new EasyIO® Variable Air Volume (VAV) IP controllers feature a powered damper actuator, and an integrated digital differential pressure transducer (DPT). The controller comes with a suite of dashboards, applications, and an onboard database. The controller features five standard applications that you can download and commission with a web browser
Features and Characteristics
• A real-time clock enables the controllers to monitor and control schedules, calenders, and trends and when offline the controllers operate as stand-alone controllers for an extended period of time
• Dual ethernet port capability facilitates a normal network switch and supports both ethernet daisy chains with up to 9 units, or up to 30 units when used within spanning tree protocol and connected in a ring
• BACnet® IP client/server, BACnet MS/TP client/ server, Modbus® TCP/RTU, M/S as well as Sox, P2P and MQTT
• Pressure pick up sensor for air flow measurement.
• 4 universal inputs (UI), 2 analog outputs (AO), and 3 digital outputs (DO). You can expand input capacity with the EasyIO FD-20i.
• Embedded program logic for common applications, or use EasyIO CPT tools to make the controller fully programmable
• HTML5 ready dashboards and is programmable live through CPT.
• Network time protocol (NTPv4) client.
• SMTP protocol for outgoing email with SSL authentication.
Support Features
• Easy connection to the wired and wireless network sensors and discharge air temperature sensors.
• IT network security standards, Wi-Fi b/g/n, and can integrate into your existing network or act as an isolated Building Management System (BMS) Wi-Fi network.
• Air flow balancing through any HTML5 compatible web browser without special tools
• SSL certificate support
• MQTT, restful API, and other web services
• SQL Lite up to 6,000 records
• Licenses and annual maintenance in the onetime cost of the controller
Specifications
| Description | Specification |
|---|---|
| Controller processor and memory specifications | |
| Main processor | Qualcomm 560 MHz |
| Processor | ARM Cortex 48 Mhz |
| Flash memory | 32 MB |
| RAM | 128 GB |
| Product temperature and humidity specifications | |
| Operating temperature | 0°C to 50°C (32°F to 122°F) |
| Storage temperature | -40°C to 70°C (-40°F to 158°F) |
| Operating humidity | 10% to 90% relative humidity, non-condensing |
| Physical specifications | |
| Dimension | 165 mm x 125 mm x 73 mm (6.5 in. x 4.9 in. x 2.9 in.) |
| Material | UL approved |
| Weight | 500 g |
| Wireless Ratings | |
| Standard | IEEE 802.11 |
| Band | b/g/n |
| Frequency range | 2412 MHz to 2462 MHz |
| Antenna | 2.2 dBi Dipole |
| Transmission power | 18.98 dBm EIRP |
