129-181-1 Fiber Optic Adapter Kit, Detector Electronics C9503/C9504 to InSight 95UVS2-2 UV Scanner
Kit that lets users of Detector Electronics fiber optics upgrade C9503 and C9504 flame scanners to a 95UVS2-2 ultraviolet InSight scanner. The bundle must reach further into the InSight than into the C9503 or C9504, so either the bundle is swapped for a longer one and the original carriers are reused as-is, or the original bundle is kept and the inner and outer carrier pipes are shortened in the field. The locking ring comes with the InSight scanner.
Key Features
- Fits: 95UVS2-2 ultraviolet InSight scanners
- Fiber protrusion (L): 0.621 in. +/- 0.005 in. (UV)
Product Specifications
| Manufacturer | Fireye |
|---|---|
| Model | 1291811 (129-181-1) |
| Type | Fiber optic adapter kit (UV), Detector Electronics fiber optics to InSight scanner |
| Fits | 95UVS2-2 ultraviolet InSight scanners |
| Adapts | Detector Electronics fiber optics used on C9503 and C9504 flame scanners |
| Fiber protrusion (L) | 0.621 in. +/- 0.005 in. (UV) |
| Installation option 1 | Replace the fiber optic bundle with a longer one; original inner and outer carriers reused without modification |
| Installation option 2 | Reuse the original bundle; cut 1.25 in. off the inner carrier pipe and re-thread (1 in. - 11 1/2 NPT), cut 1.00 in. off the outer carrier |
| Parts used | Flange, 1 1/4 in. coupling, adapter, gauge tube, (3) #4-40 socket-head cap screws, (3) #6-32 and (3) 1/4-20 setscrews |
| Locking ring | Supplied with the InSight scanner |
| Cooling air | 3/8 in. NPT inlet on the new flange; use a 3/4 in. to 3/8 in. thread reducer on the existing air line |
| Lens position | 5/16 in. from the end of the fiber optics (option 1, new bundle) |
| Sibling | 129-181-2: IR, for 95IRS1-2 and 95IRS2-2 |
